	Torsion Resistant Rubber Cable Hits：522 Time：2015-08-27 08:17:16 I want to order

Description

Application

Torsion Resistant Rubber Cable torsion resistant rubber cable is used as a connecting cable for windmill. It can be used either in dry or damp areas and suitable for outdoor application.

Technical data

Specific insulation resistance

1 GOhm x cm

Temperature range

Flexible use: -15 °C to +90 °C

Wind energy: -40 °C to +90 °C

Fixed installation: -40°C to +90 °C

Nominal voltage 450/750 V

Test voltage 2500 V

Minimum bending radius

Flexible use: 6 x outer diameter

Fixed installation: 5 x outer diameter

Cable structure

Bare copper wire according to HAR

Outer jacket of rubber

Properties

Flame retardant according to IEC 60332-1-2

Torsion-resistant

Oil resistant to most transmission oils

Abrasion- and cut-resistant; cold-flexible;

ozone-resistant according to HD 22, EN 60811-2-1

and EN 50396-8.1.3

Cross-sec. mm²	Outer Diameter mm	Copper Weight kg/km	Cable Weight kg/km
95	20.8 - 23.5	912	1300
120	22.8 - 25.0	1152	1500
150	25.2 - 27.8	1440	1850
185	27.6 - 30.1	1776	2200
240	30.6 - 33.9	2304	2900
300	33.5 - 36.7	2880	3400
400	37.4 - 46.8	3840	4400
